PVDF Capsule Filter

Hydrophilic PVDF membrane, ideal for buffers and WFI

Product Code: XyCap-C-PVDF

Catalog Number Description Membrane Connection
XyCap-C-PVDF-4TC Size 4 PVDF capsule, gamma sterilized, with 0.021 m² area and tri-clamp for sealed sterile line integration. Hydrophilic PVDF Tri-Clamp
XyCap-C-PVDF-4HB Size 4, gamma-sterile PVDF capsule filter with 0.021 m² area and hose barb for flexible tubing and low-extractable use. Hydrophilic PVDF Hose Barb
XyCap-C-PVDF-4LL Size 4, gamma-sterile PVDF capsule filter with 0.021 m² area and luer lock for compact low-volume process setups. Hydrophilic PVDF Luer Lock

Catalog Number:

XyCap-C-PVDF-4TC

Description:

Size 4 PVDF capsule, gamma sterilized, with 0.021 m² area and tri-clamp for sealed sterile line integration.

Membrane:

Hydrophilic PVDF

Connection:

Tri-Clamp

Product Description

PVDF Capsule Filters (Hydrophilic – Low Extractables)

Available Sizes: Size 4
Connection Types: Hose Barb, Tri-Clamp, Luer Lock
Membrane Composition: Hydrophilic PVDF
Filtration Area: 0.021 m²
Sterilization: Gamma-Irradiated

XyCap PVDF Capsule Filters are specialized for low extractable liquid filtration, making them ideal for final filtration of buffers, WFI (Water for Injection), and protein-sensitive solutions. They incorporate a hydrophilic polyvinylidene fluoride (PVDF) membrane, known for its exceptionally low protein binding and superior filtration clarity. These filters are fully integrity-tested and gamma sterilized, supporting stringent requirements in sterile manufacturing, especially where minimizing leachables is critical.

Use Cases

  • Final filtration of WFI, buffers, and low ionic strength solutions
  • Sterile filtration in protein or enzyme-sensitive workflows
  • Fill/finish filtration requiring extractables control
  • QC and lab workflows involving high-purity fluids
  • Pre-filtration of therapeutic proteins

Product Features

  • Hydrophilic PVDF membrane: Low extractables and excellent flow characteristics
  • Minimal protein binding: Ideal for protein-based drug applications
  • Excellent clarity: Maintains high fluid purity post-filtration
  • Sterile ready: Gamma-irradiated, integrity-tested
  • Multiple fittings: Hose Barb, Tri-Clamp, Luer Lock
  • Size 4 capsule format: Compact and scalable, 0.021 m² filtration area
